SF RED. FLANGE
Slim flange from SIMONA, made from black PE100 and designed for SDR17 pipes and only for buttwelding.. The flange is approved for 10 bar water pressure and is supplied complete with loose backing flange and EPDM gasket. This space-saving solution has been developed with a strong focus on drinking water hygiene.
Thanks to the slim design with no dead spaces, the risk of bacterial buildup is minimized, ensuring a high hygiene standard in potable water installations. The precise fit eliminates misalignment, providing optimal flow and low pressure loss. By using valves of the same nominal diameter, significant cost savings can be achieved. The entire component is naturally corrosion-resistant, offering a low-maintenance and long-lasting solution
Need help?
At Plast-Line we are always ready to help! Contact us by phone at +45 63404100 or by email at ordre@plast-line.dk with questions about our products. Your satisfaction is our priority!
| Dia. | Name | Nominal Diameter | SDR | Sub material | ||
|---|---|---|---|---|---|---|
250 | SF RED. FLANGE 30071250 | 200 | 17 | PE100 | ||
400 | SF RED. FLANGE 30071400 | 350 | 17 | PE100 |
